详细介绍
产品设备软件应用：具有广泛性应用软件于生物技木学品整理，保健食品咖啡饮料，医疗管理有效研究，水整理建筑项目，药厂类，实践室，印，生物技木技木，光电器件，生物有效（安排和上皮细胞塑造培养，沤肥）等该行业。躯干注射器液，血清类卸料。中含邻苯二甲酸盐塑化剂，是不会溶入别的传导粘液。
护肤品基本特征：装修材料：卫生管理级珀金硅胶材料料精加工而成。面上：面上要求高，未很多中药味，透明。具备有非溶顽强。——无嗅、淡而无味,仍然无磷，因为没有含其他塑化剂和“增白剂组分。仍然满足肉食品FDA和生物技术医疗仪器级USP VI的想要。——哪些管平常是内层为公开白金硫化橡胶矽胶。
高品质认正：——橡胶软管凭借荷兰FDA 21 CFR 177.2600(食材厂和药材管控局)食材厂级认可。——软水管完成美国BfR部件 XV的标准审核和LFBG审核。——软水管根据欧盟成员国指令表2008/95 / ECC的限定运行部分威害有害物(RoHS)同意。——塑料软管合乎ISO10993,NSF51和欧式药典3.1.9的规定要求。Product application:Widely used in chemical materials treatment, food and beverage, medical research, water treatment projects, pharmaceutical, laboratory, printing, biological technology, semiconductor, Life sciences (tissue and cell culture, fermentation), etc.also used for human injection and serum delivery. The hose does not contain adjacent benzene two formate plasticizer and the transmission fluid will not penetrate.
Product description:-used in liquid and semi fluid food of medicine and cosmetic products, bio engineering.-Standard length is 20 meters per roll, and we can also to produce the specified size and length according to customer requirements.Our hose products has passed the certification of the United States FDA grade and Class VI USP and German BFR.
Product characteristics:Material:Sanitary grade platinum silicone materials.Surface: high accuracy on the surface,tasteless, colorless and Non hemolytic-odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully meet the requirements of food FDA and biological medical grade VI USP.-the outer layer of these hoses is the transparent platinum vulcanization silicone.
Quality certification:-pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.-pass the German BFR parts XV standard certification and LFBG certification.-in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.-in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
| 东莞市xk星空体育硅胶制品有限公司 |
BH00铂金硅胶蠕动泵管
Platinum silicone hose (pump hose) BH00 |
|
品名
PART NAME | 管号
HOSE NO | 内径
INNER DIA | 外径
OUTER DIA | 弯曲半径
BEND RADIUS | 真空度
VACUUM | 标准长度
STANDARD LENGTH |
| mm | inch | mm | inch | mm | inch | Bar | Psi | 米/根
METERS PER PC |
| BH00-015 | #15 | 4.76 | 3/16" | 7.92 | 0.31" | 20 | 0.79 | N/A | N/A | 15 |
| BH00-016 | #16 | 3.18 | 1/8" | 6.34 | 0.25" | 30 | 1.18 | N/A | N/A | 15 |
| BH00-017 | #17 | 6.35 | 0.25" | 9.60 | 0.36" | 40 | 1.57 | N/A | N/A | 15 |
| BH00-018 | #18 | 7.90 | 0.31" | 11.11 | 0.42" | 60 | 2.36 | N/A | N/A | 15 |
| BH00-024 | #24 | 6.40 | 0.25" | 11.40 | 0.42" | 90 | 3.54 | N/A | N/A | 15 |
| BH00-025 | #25 | 4.80 | 3/16" | 8.00 | 0.31" | 110 | 4.33 | N/A | N/A | 15 |
| BH00-026 | #26 | 6.40 | 0.25" | 13.00 | 0.52" | 150 | 5.91 | N/A | N/A | 15 |
| BH00-035 | #35 | 7.90 | 0.31" | 14.70 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-036 | #36 | 9.50 | 0.37" | 14.70 | 0.43" | 280 | 11.02 | N/A | N/A | 15 |
| BH00-070 | #70 | 7.90 | 0.31" | 18.90 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-073 | #73 | 7.90 | 0.31" | 16.10 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-082 | #82 | 12.70 | 0.50" | 19.30 | 0.75" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-087 | #87 | 12.70 | 0.50" | 25.30 | 1.00" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-088 | #88 | 12.70 | 0.50" | 22.20 | 1.00" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-089 | #89 | 15.90 | 0.62" | 22.20 | 0.87" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-091 | #91 | 19.05 | 0.75 | 32.60 | 1.25" | 350 | 13.78 | N/A | N/A | 15 |
